Applications:
LG series vertical type screw air compressor widely used in textile, spraying, chemical, food, electronic, medical, railway, building materials and military industries.
Features:
1.Supporting large rotor, low speed and high quality main engine, high efficiency, low noise, long life, especially suitable for low noise working occasions.
2.External oil and gas separation core, rated flow is much larger than exhaust, good oil effect, long service life, easy maintenance.
3.Supporting imported brand air and oil filters to provide the best protection for the nose.
4.Microcomputer control, complete control and protection functions, data settings adjustment, fault inquiry convenient, realize unattended.
Parameter Table：
|
Model
|
LG7EZ
|
LG11EZ
|
LG22EZ
|
LG37EZ
|
LG55EZ
|
LG75EZ
|
|
Air Displacement(m3/min)
|
1.15
|
1.65
|
3.6
|
6.1
|
10.2
|
13.5
|
|
Working Pressure(bar)
|
8
|
8
|
8
|
8
|
8
|
8
|
|
Compression stage
|
1
|
1
|
1
|
1
|
1
|
1
|
|
Motor Model
|
Y2-132S2-2
|
Y2-132M-2
|
LY-160L-2
|
LY-180L-2
|
Y2-225M-2
|
Y2-250M-2
|
|
Motor power(kw)
|
7.5
|
11
|
22
|
37
|
55
|
75
|
|
Rotate speed(rpm)
|
2950
|
2950
|
2950
|
2950
|
2950
|
2950
|
|
Voltage(V/P/Hz)
|
380/3/50
|
380/3/50
|
380/3/50
|
380/3/50
|
380/3/50
|
380/3/50
|
|
Start method
|
Y-Δ
|
Directly
|
Y-Δ
|
Y-Δ
|
Y-Δ
|
Y-Δ
|
|
Transfer method
|
Direct-driven
|
Direct-driven
|
Direct-driven
|
Direct-driven
|
Direct-driven
|
Direct-driven
|
|
Connector size
|
3/4"
|
3/4"
|
1"
|
11/2"
|
|
|
|
Cooling method
|
Air Cooling
|
Air Cooling
|
Air Cooling
|
Air Cooling
|
Air Cooling
|
Air Cooling
|
|
Dimension(L*W)mm
|
800*520*840
|
1020*640*865
|
1300*750*1200
|
1300*880*1250
|
1600*970
*1450
|
1750*1030
*1450
|
|
Weight(kg)
|
200
|
300
|
550
|
750
|
1300
|
1600
|
